With ground breaking technological application, we offer definite advantages of Plain Dutch weave as well as Twilled Dutch weave for application in BOPP Film Plants, Woven Sacks, PET and non-woven fabric plants. Available in sizes ranging from 12/72, 24/110, 40/200, 50/250, 80/400, 100/600, 165/800, 165/1400, 200/600 and 200/1400 custom made screen are also provided at Ambica.


-	Circular Screen
-	Multilayer Circular Screen Pack
-	Multilayer Cylindrical Screen Pack
-	Multimesh Circular Screen
-	Hopper Magnet
-	Designer Screens
-	Filter Discs
-	Stainless Steel Wire Mesh & Woven Wire Cloth

PLAIN-DUTCH WEAVE :

The pattern of this mesh is the same as in plain weave except that the warp wires are of a larger diameter than the shute wires and the shute wires are driven up close to each other, resulting in tapers or wedge-shaped opening instead of square opening. In dutch weave the warp wires remain in straight conditions and the shute wires are crimped.

TWILLED-DUTCH WEAVE :

Wire cloth which has the same pattern as twilled weave e x cept the warp wires are of a larger diameter than the shute wires & the shute wires are driven up tapers or wedge-shaped opening. Warp wires remain in a straight condition, but the shute wires take all the crimp. Due to the twilled weave construction, the shute wires are not only deformed in depth (crimps when formed around the warp wires) but also sideways.

Product Specifications
PLAIN AND TWILL DUTCH WEAVE FILTER CLOTH
WARP/SHUTE MESH	GAUGE	WIRE DIAMETER	NOMINAL MICRON RETENTION
12/64	26 x 26	0.457 x 0.457	180
24/110	28 x 32	0.376 x 0.274	115
30/250	38 x 42	0.132 x 0.102	70
50/250	38.5 x 41	0.140 x 0.112	60
50/600	40 x 44	0.122 x 0.081	30
80/400	40 x 45.5	0.102 x 0.063	40
80/700	42 x 44	0.102 x 0.063	35
100/600	42 x 45.5	0.102 x 0.081	25
120/600	42 x 45.5	0.102 x 0.063	28
170/1400	43.5 x 48	0.063 x 0.040	10
200/600	47 x 48	0.50 x 0.040	20
325/2300	48 x 40	0.40 x 0.122	5
